Cambium ePMP 5 GHz Force 425 SM 2-pack packaging priced per radio (IC) (Canada/US cord)
Cambium ePMP 5 GHz Force 425 SM 2-pack packaging priced per radio (IC) (Canada/US cord)
There are 7 units left in stock.
Couldn't load pickup availability
Cambium Networks C058940M104A
ePMP 5 GHz Force 425 SM 2-pack packaging priced per radio (IC) (Canada/US cord)
Cambium Networks introduces the ePMP™ Force 425 point-to-point solutions, delivering up to 1 Gbps throughput at a breakthrough price point, based on the latest 802.11ax standards and Cambium’s proprietary ePTP protocol. The Force 400 Series is the ideal solution for service providers looking to deliver high-capacity access services to enterprise and residential customers. It also serves as a low-cost backhaul for MicroPOPs and outdoor Wi-Fi access points that require a lot of capacity at moderate range without the overhead of licensed microwave. With an integrated SFP port and optional GPON ONU module, the Force 425 makes a great fiber extension to reach places where fiber cannot.
The Force 425 pushes this capacity farther with an integrated 25 dBi dish (and even farther with the optional 28 dBi range extender). The optional range extender is ordered separately and can be assembled and attached in the field to add additional link budget and fade margin for challenging links or to move to higher capacity, where needed, and higher modulations, where achievable.
Specifications C058940M104A
| Channel Width MHz | 20 | 40 | 80 |
| Proprietary Physical Layer | 802.11ax, 2x2 MIMO/OFDM |
| Channel Spacing | Configurable in 5 MHz increments |
| Frequency Range | Wide Band Operation 4910 - 6135 MHz |
| MAC Layer (Media Access Control) | Cambium Proprietary |
| Ethernet Interface | 100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts; 10 Gigabit SFP cage for optional SFP modules Protocols |
| Used | IPv4/IPv6 (Dual Management Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH |
| Network Management | IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro™ |
| VLAN | 802.1Q with 802.1p priority |
| Performance | |
| ARQ | Yes |
| Maximum Capacity | 1 Gbps |
| Latency | < 5 ms |
| Nominal Receive Sensitivity (w/FEC) @20 MHz Channel | MCS 0 = -93 dBm to MCS 11 (1024 QAM-5/6) = -63 dBm (per chain) |
| Nominal Receive Sensitivity (w/FEC) @40 MHz Channel | MCS 0 = -90 dBm to MCS 11 (1024 QAM-5/6) = -60 dBm (per chain) |
| Nominal Receive Sensitivity (w/FEC) @80 MHz Channel | MCS 0 = -87 dBm to MCS 11 (1024 QAM-5/6) = -57 dBm (per chain) |
| Modulation Levels (Adaptive) | MCS 0 (BPSK) to MCS 11 (1024 QAM-5/6) |
| Transmit Power Range | +3 to +28 dBm (combined, to regional EIRP limit) (1 dB interval) |
| Physical | |
| Connectors | 1 x RJ-45, 1 x SFP |
| Surge Supression* | 1 Joule Integrated |
| Environmental | IP67 |
| Temperature | -30°C to 65°C (-22°F to 149°F) |
| Weight | 4.8 kg (10.6 lbs.) |
| Wind Survival | 200 km/hour (124 mph) |
| Dimensions(H x W x D) | 470 mm diameter x 285 mm depth (18.5 in diameter x 11.2 in depth) |
| Pole Diameter Range | Center: 3.1 to 7.6 cm (1.25 to 3.0 inches) |
| Power Consumption | 28 W |
| Security | |
| Encryption | 128-bit Over-the-Air Encryption (256-bit AES where export rules allow - ROADMAP Feature) |
| Certifications | |
| FCC Regulatory Part Number | C058940P102A |
| FCC ID** | Z8H89FT0062 |
| ETSI/ROW Regulatory Part Number | C050940P001A |
| Industry Canada Cert** | 109W-0062 |
| CE | EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)** |
| Antenna Spec | |
| Frequency Range | 4910 – 6135 MHz |
| Antenna Type | Dish |
| Peak Gain | 25 dBi |
| 3 dB Beamwidth Azimuth | 7º |
| 3 dB Beamwidth Elevation | 7º |
| Front-To-Back Isolation | TBD |
| Cross Polarization | TBD |
